1. The inner chamber is made of 304 stainless steel;
2. 5-inch touch screen display shows parameters such as temperature, rotation speed, and time;
3. Stable rotation speed and excellent temperature control;
4. Combines a constant temperature incubator and shaker into one unit, saving space, reducing footprint, and offering multiple functions with less investment;
5. Tilted, user-friendly control panel with a large backlit LCD screen for excellent visual effect;
6. Personalized program design allows for pre-setting up to ten programmable segments and the option to loop the program, enabling automatic operation of temperature, rotation speed, and time;
7. Quiet operation design, electrostatic spray-coated casing, and tempered glass observation window allow for monitoring temperature and lighting conditions inside the chamber at any time;
8. Multiple timing modes: 1. Timing units can be freely switched between minutes and hours; 2. Two timing modes: timing starts upon power-on or after reaching a constant temperature;
9. Shaking direction can be switched between forward and reverse;
10. Built-in lighting system and UV sterilization system;
11. Temperature control can be turned off, controlling only the rotation speed; or rotation speed can be turned off, controlling only the temperature; multiple modes can be freely switched;
12. The compressor uses automatic control, the temperature control range is not affected by room temperature, 4~60 degrees Celsius is arbitrarily controllable, and the compressor can automatically defrost (Type A);
13. Large-angle observation window provides a clear view of the entire working status;
14. Quiet operation design, electrostatic spray-coated casing, luxurious and beautiful appearance;
15. Stable constant temperature function prevents sample evaporation and drying;
16. Air inlet with filter to prevent contamination;
17. AC induction long-life motor design, wide speed range, constant torque, constant speed, brushless, maintenance-free;
18. Mirror-polished stainless steel inner lining, stainless steel electropolished tray, springs, and flask clamps. The instrument is corrosion-resistant;
19. Flexible and convenient, the tray and clamps are detachable.
|
Model |
DSL-YE180A |
DSL-YE180B |
DSL-YE280A |
DSL-YE280B |
DSL-YGE50A |
DSL-YE550B |
|||||
|
Temperature Control Range |
4～60℃ |
RT+5～60℃ |
4～60℃ |
RT+5～60℃ |
4～60℃ |
RT+5～60℃ |
|||||
|
Display Method |
LCD |
||||||||||
|
Temperature Resolution |
±0.1℃ |
||||||||||
|
Temperature Fluctuation |
±0.5℃ |
||||||||||
|
Temperature Uniformity |
±1℃ |
||||||||||
|
CO2 Control Range |
0～20% |
||||||||||
|
CO2 Recovery Time |
≤Concentration value × 1.2 min |
||||||||||
|
CO2 Control Method |
≤Concentration value × 1.2 min |
||||||||||
|
Timer Range |
0~999 Hour |
||||||||||
|
Oscillation Amplitude |
φ26mm |
φ35mm |
|||||||||
|
Rotation Frequency |
40~300rpm |
60～280rpm |
|||||||||
|
Speed Accuracy |
±1rpm |
||||||||||
|
Mixing Mode |
Rotary |
Reciprocating |
Rotary |
Reciprocating |
Rotary |
Reciprocating |
|||||
|
Number of Tray |
2 |
||||||||||
|
Lighting Method |
UV/Fluorescence (choose one) |
||||||||||
|
Tray Dimensions |
500mm×350mm |
740mm×460m |
970mm×560mm |
||||||||
|
Volume |
180L |
280L |
550L |
||||||||
|
Interior Dimensions（W*D*H） |
660mm×440mm×650mm |
840mm×520mm×640mm |
1080mm×630mm×805mm |
||||||||
|
Exterior Dimensions（W*D*H） |
700mm×560mm×1260mm |
950mm×700mm×1260mm |
1200mm×800mm×1500mm |
||||||||
|
Default Factory Settings |
250ml×24 tubes |
250mlx35 tubes or 500ml×24 tubes |
250ml×45 tubes or 500ml×36 tubes |
||||||||
|
Maximum Capacity |
100ml×48 tubes or 250ml×24 tubes or 500ml×24 tubes |
250mlx70 tubes or 500ml×48 tubes or 1000ml×24 tubes |
250ml×90 tubes or500ml×74 tubes |
||||||||
|
Power |
550W |
380W |
550W |
750W |
960W |
750W |
|||||
|
Net Weight |
185KG |
165KG |
240KG |
220KG |
380KG |
355KG |
|||||
|
Power Supply Voltage |
AC220V~240V±10% 50～60HZ |
||||||||||
