Explosion-proof air conditioners are specialized equipment that integrates explosion-proof technology, refrigeration technology, and intelligent control. Their core mission is to create a safe, stable, and controlled microclimate in extremely hazardous environments containing flammable and explosive gases, vapors, or dust. They are widely used in industries such as energy and chemical engineering, hazardous materials handling, powder metallurgy, fine chemicals, 3D printing metal dust environments, lithium battery production, military and aerospace, food and pharmaceuticals, and scientific research laboratories.
① Complies with the national GBT 3836.1-2021 explosion-proof standard, incorporating multiple explosion-proof types including flameproof, increased safety, intrinsic safety, and encapsulation. Key components feature a spark-free design for proactive safety, completely mitigating risks at the energy source and creating a safe production environment;
② Equipped with cutting-edge explosion-proof technology, certified to the rigorous national IIC T4 standard. The advanced explosion-proof system can handle various complex and high-risk gas conditions, ensuring stable and safe operation in diverse hazardous gas environments;
③ Utilizes a microcomputer-integrated intelligent temperature control system with a built-in microcomputer chip that collects real-time temperature change data;
④ We provide a comprehensive after-sales service network covering most areas of the country, ensuring worry-free use for our customers (Note: excluding a few extremely remote towns and villages);
⑤ We offer comprehensive free technical services, including video, telephone, and online video tutorials, to intuitively demonstrate equipment performance and operation methods, helping users quickly master operation and troubleshooting.
① Casing Material: Made of selected high-quality cold-rolled steel plate (Q235), precisely formed by CNC machining. The surface is treated with phosphating and anti-static powder coating, creating a sturdy casing that is anti-static, corrosion-resistant, and scratch-resistant, ensuring consistent and durable quality;
② Aluminum fin hydrophilic film evaporator: Features a 0.1mm hydrophilic aluminum foil material for stain resistance and easy cleaning, enabling rapid condensation and significantly improving heat transfer efficiency; the inner grooved copper tubes greatly enhance cooling efficiency;
③ High-sensitivity explosion-proof temperature control panel: Provides accurate temperature control; electrical components use high-quality brand-name components, ensuring high sensitivity, stability, and reliability;
|
Model |
BKFR-25 |
BKFR-35 |
BKFR-50 |
BKFR-75 |
BKFR-50 |
BKFR-72 |
BKFR-120 |
|
Explosion-proof Rating |
IIC T4 |
||||||
|
Type |
Suitable for both heating and cooling. |
||||||
|
Specification |
1P/Wall-mounted air conditioner |
1.5P/Wall-mounted air conditioner |
2P/Wall-mounted air conditioner |
3P/Wall-mounted air conditioner |
2P/Cabinet air conditioner |
3P/Cabinet air conditioner |
5P/Cabinet air conditioner |
|
Applicable Area ㎡ |
10～15 |
15～22 |
22～34 |
34～5 |
22～3 |
34～5 |
55～85 |
|
Cooling Capacity |
810W |
1068W |
1600W |
2350W |
1620W |
2350W |
3950W |
|
Heating Power |
770W |
1200W |
1680W |
2700W |
1720w |
2350W |
3800W |
|
Circulating Air Volume |
520m³/h |
650m3/H |
1000m³/H |
1200m³/H |
900m³/H |
1300m³/H |
2000m³/H |
|
Indoor Unit Noise |
35dB |
35dB |
36dB |
37dB |
42dB |
42-46dB |
50dB |
|
Indoor Unit Dimensions (mm) |
780*200*300 |
830*200*300 |
975*310*230 |
1080*330*250 |
500*350*1720 |
520*350*1770 |
580*400*1870 |
|
Outdoor Unit Dimensions (mm) |
735*330*555 |
735*330*555 |
960*400*700 |
1050*450*850 |
880*380*560 |
960*400*660 |
950*400*800 |
|
Power Supply Voltage |
AC220V |
AC220V |
AC220V |
AC220V |
AC220V |
220V/380V |
AC220V |
|
Total Power |
1.58KW |
3.2KW |
4.5KW |
6.2KW |
4.5KW |
6.5KW |
11.2KW |
|
Net Weight of Indoor and Outdoor Units |
13/37KG |
15/38KG |
18/41KG |
21/55KG |
38/40KG |
42/46KG |
61/106KG |
