1. Equipped with a specially designed gas ballast valve to prevent pump oil from mixing with water, extending the service life of the pump oil;
2. High pumping efficiency, high ultimate vacuum, and long service life;
3. Equipped with an automatic anti-backflow check valve, ensuring no oil backflow;
4. Small-diameter 2XZ-2B, 2XZ-4B, and 2XZ-8B vacuum pumps are specifically designed for vacuum drying ovens, freeze dryers, and printing machinery;
5. Can be equipped with small-diameter conversion connectors, KF interfaces, and flange interfaces;
6. When pumping gases containing vapor, particles, or corrosive gases, auxiliary equipment such as condensers and dust collectors must be installed at the pump's gas inlet.
|
Model |
2XZ-2B |
2XZ-4B |
2XZ-6B |
2XZ-8B |
2XZ-15B |
2XZ-25B |
|
Theoretical Pumping Speed m3/hr |
7.2 |
14.4 |
21.6 |
28.8 |
54 |
90 |
|
Theoretical Pumping SpeedL/S |
2 |
4 |
6 |
8 |
15 |
25 |
|
Extreme Pressure |
≤4*10-2 |
|||||
|
Extreme Pressure |
≤1Pa |
|||||
|
Motor Speed |
1400r/min |
|||||
|
Power Supply Voltage |
AC220V/50Hz |
AC380V/50Hz |
||||
| Noise dB |
62 |
65 |
66 |
|||
|
Inlet Diameter （outside） |
Φ30 |
Φ40 |
Φ50 |
|||
|
Inlet Flange |
KF25 |
KF40 |
KF50 |
|||
|
Fuel Volume (L) |
0.8 |
0.95 |
1.2 |
2.4 |
3 |
6 |
|
Exterior Dimensions(L*W*H) mm |
514*168*282 |
565*168*282 |
560*240*340 |
650*240*430 |
700*240*430 |
770*240*430 |
|
Power |
0.37 |
0.55 |
0.75 |
1.5 |
2.2 |
|
|
Net Weight (KG) |
20 |
22 |
40 |
60 |
75 |
85 |
|
Cooling Method |
Air Cooling |
|||||
|
Ambient Temperature℃ |
5~35 |
|||||
