1. The light source uses eight imported ultraviolet fluorescent lamps with a rated power of 40W. The ultraviolet fluorescent tubes are distributed on both sides of the machine, with four on each side. UVA-340 and UVB-313 light sources are available for user selection and configuration;
3. The luminous spectral energy of the UVA-340 lamp is mainly concentrated at a wavelength of 340nm, and the luminous spectrum of the UVB-313 lamp is mainly concentrated around 313nm;
4. This equipment uses UVA-340 lamps;
5. Because the light energy output of fluorescent lamps gradually attenuates over time, to reduce the impact of light energy attenuation on the test, this test chamber replaces one old lamp with a new one every 1/4 of the fluorescent lamp's lifespan among all eight lamps. In this way, the ultraviolet light source always consists of new and old lamps, thus obtaining a constant light energy output;
6. The effective service life of the lamp is approximately 1600 hours;
7. The equipment uses a true-color touch screen PID intelligent temperature controller, which has high temperature control accuracy and good stability;
Box Structure
1. Test Chamber Space: 1100 × 550 × 400mm (width * depth * height)
2. Overall Dimensions: Approximately 1340 × 1250 × 1560mm (width * depth * height)
3. Unit Material: Inner and outer 304 stainless steel
4. Specimen Holder: Aluminum alloy frame base plate
5. Controller: TIMI880 (full touch screen programmable controller) 6. Power supply controlled by leakage circuit breaker, with overload and short-circuit alarm, over-temperature alarm, and water shortage protection.
7. Operating requirements: Capable of radiation, spraying, and condensation cycle operation;
8. Temperature range: RT+10℃~70℃;
9. Illumination temperature range: 20℃~70℃ / Temperature tolerance: ±2℃
10. Temperature fluctuation: ±0.5℃;
11. Humidity range: ≥90%RH
12. Humidity fluctuation: ±2%;
13. Lamp center distance: 70mm;
14. Distance between sample and lamp center: 50mm;
15. Water tank depth requirement: 25mm, automatic control;
16. Effective irradiation area: 1100×550×400mm;
17. Radiation intensity: Adjustable within 2.0W/m2;
18. Ultraviolet wavelength: UVA range 315-400nm;
19. Black panel thermometer measurement range: 20℃~90℃ / Temperature tolerance: ±1℃;
20. Alternating UV light and condensation time are adjustable;
21. Black panel temperature: 40℃~65℃;
22. Lamp tubes: L=1200/40W, 8 tubes (UVA, service life >1600h)
23. Water tank depth: 25mm, automatic control
24. Test time: 0~999H (adjustable)
25. The unit has an automatic spraying function.
Safety Protection
1. Over-temperature protection: When the temperature inside the chamber exceeds 93℃±10%, the machine will automatically cut off the power supply to the lamps and heaters and enter a cooling state;
2. Low water level alarm in the water tank to prevent the heater from dry burning;
1. The cabinet is manufactured using CNC equipment, featuring advanced technology, smooth lines, and an elegant appearance;
2. The cabinet material is 1.0mm thick 304SUS high-grade stainless steel;
3. The internal air duct adopts a single-circulation system with an imported axial fan, improving airflow and heating capacity, and significantly improving temperature uniformity inside the test chamber;
4. Water source and consumption: Tap water or distilled water, approximately 8 liters/day;
5. The heating method is an inner tank water bath heating system, providing rapid heating and uniform temperature distribution;
6. The door is a single-direction pull-out type, easy and smooth to open and close;
7. The inner tank water level is automatically replenished to prevent damage to the heating element due to dry burning;
8. The sample holder is made of stainless steel or aluminum alloy;
9. The unit is fixed with high-quality PU casters at the bottom;
10. The drainage system uses a U-shaped sedimentation device for drainage;
11. The sample surface is parallel to the UV lamp plane;
The spraying system is equipped with automatic nozzles internally, and the water pressure is adjustable.
1. Both blackboard temperature and condensation temperature are controlled by a controller;
2. Other components mainly use imported electronic components; Irradiance uniformity: ≤4% (at the sample surface);
3. Blackboard temperature monitoring: A standard Pt-100 blackboard temperature sensor is used to accurately control the sample surface temperature during the test process;
4. Blackboard temperature setting range: BPT 40-75℃;
5. Temperature protection device temperature: The maximum temperature limit is 93℃±10%;
6. Blackboard temperature control accuracy: ±0.5℃;
7. Water tank temperature monitoring: During the cyclic test process, one test segment is a dark condensation process, which requires saturated water vapor at a relatively high temperature to be generated inside the chamber. When the water vapor encounters the relatively cooler sample surface, dew will condense on the sample surface;
8. The water tank is located at the bottom of the chamber and has a built-in electric heater;
9. Water tank temperature control range: 40~60℃;
10. The test chamber is equipped with a time controller, range 0~530H, with power failure memory function;
| Working Chamber Dimensions | 1140mm × 400mm × 380mm |
| Overall Dimensions | 1300mm × 500mm × 1460mm |
| Lamp Center Distance | 70mm |
| Closest Parallel Distance from Specimen to Lamp Surface | Approximately 50mm |
| Wavelength Range | UV-A wavelength range is 315~400nm |
| Radiation Intensity | 1.2W/m²/340nm |
| Temperature Resolution | 0.1℃ |
| Illumination Temperature Range | 50℃~70℃ / Temperature Tolerance: ±3℃ |
| Condensation Temperature Range | 40℃~60℃ / Temperature Tolerance: ±3℃ |
| Black Panel Thermometer Measurement Range | 30~80℃ / Tolerance: ±1℃ |
| Temperature Control Method | PID self-tuning temperature control |
| Humidity Range | Approximately 45%~70% R.H (illumination state) / Above 98% (condensation state) |
| Water Tank Requirements | Water depth not greater than 25mm, with automatic water supply controller |
| Standard Specimen Size | 75×150mm, 48pcs |
| Recommended Instrument Operating Environment | 5~35℃, 40%~85% R.H, 300mm distance from the wall |
Products provided by famous enterprises are deeply trusted by users.
Shanghai Dengsheng Instrument Manufacturing Co., Ltd. is a high-tech enterprise integrating R&D, production, sales, and service. We specialize in the manufacture of high-end laboratory equipment, including ovens, incubators, industrial furnaces, and environmental test chambers.
As Over-temperature protection UV Aging Test Chamber Manufacturers and Over-temperature protection UV Aging Test Chamber Factory in China, We boast an 8,000-square-meter modern production facility, a dedicated R&D team, 23 national patents, and ISO-9001 quality management system certification. Our solutions are widely used in cutting-edge fields such as aerospace, semiconductors, biomedicine, automotive, and new materials. We have established in-depth partnerships with top universities and industry leaders, supply Over-temperature protection UV Aging Test Chamber Wholesale, our products are exported to many countries and regions around the world.
Adhering to the principles of "Integrity, Innovation, and Win-Win," we are committed to becoming your trusted partner with reliable quality and dedicated service.
We welcome inquiries and cooperation from both new and existing customers, providing professional equipment solutions.
