1. Utilising xenon arc lamps capable of simulating the full solar spectrum to reproduce destructive light waves present in diverse environments, these systems provide corresponding environmental simulation and accelerated testing for scientific research, product development, and quality control.
2. The DHX series xenon arc lamp test chambers are suitable for selecting new materials, modifying existing materials, or assessing changes in durability following alterations to material composition. They effectively simulate alterations occurring when materials are exposed to sunlight under varying environmental conditions.
3. Accelerated ageing tests are conducted by exposing material specimens to the light and thermal radiation of xenon arc lamps. This evaluates the lightfastness and weather resistance of certain materials under high-temperature light sources. Primarily used for automotive components, coatings, rubber, plastics, pigments, adhesives, textiles, and similar materials.
1. Imported colour touchscreen control system, delivering precise temperature regulation with high sensitivity;
2. High-temperature resistant, high-expansion sealing strips, tested over ten thousand cycles, exhibit robust elasticity and maintain shape integrity, ensuring chamber airtightness;
3. Turntable utilises an extra-long shaft motor, constructed from high-temperature resistant stainless steel to guarantee dimensional stability, uniform rotation, and even heating of test specimens;
4. Specimen racks constructed from high-strength stainless steel, facilitating easy cleaning without affecting chamber temperature during testing;
5. Standard test port (50mm) for convenient connection of test power cables or signal lines;
6. The observation window employs multi-layered hollow tempered glass, ensuring safe operation during testing;
7. For ease of movement, the unit incorporates PU swivel castors with locking feet, facilitating both mobility and secure positioning;
8. The modular control system incorporates an alarm system, phase failure protection, and earth leakage protection, delivering truly worry-free testing.
| Model | DHX-150 | DHX-225 | DHX-408 | DHX-800(A.B) | DHX-1000(A.B) |
| Light Source | 1 | 1 | 2 | 3/1 | 3/1 |
| Inner Chamber Dimensions | 500z500x600 | 500x600x750 | 800x600x850 | 800x1000x1000 | 1000x1000x1000 |
| Overall Dimensions | 1050x1050x1750 | 1050x1200x1950 | 1350x1200x2050 | 1350x1600x2200 | 1600x1600x2200 |
| Continuous Illumination Duration | 2000 hours | ||||
| Temperature Range | Blackboard temperature: 40–110°C Black panel temperature: 40–120°C | ||||
| Temperature Deviation | ±2°C | ||||
| Humidity Range | With illumination: 10–70% RH Without illumination: 30–95% RH | ||||
| Humidity Deviation | ±39RH | ||||
| Irradiation Control | 290~800nm | ||||
| Cooling Method | Air-cooled | Type A: Air-cooled / Type B: Water-cooled | |||
| Rainfall Duration | 1" 999 min adjustable | ||||
| Rainfall Interval | 1~240 min adjustable | ||||
| Water Circulation System | 1: Deionised water 2: Water pressure 1.5 kg/cm³ 3: Flow rate 2 L/min | ||||
| Inner Chamber Material | Stainless steel | ||||
| Outer Enclosure Material | Stainless steel | ||||
| Power Supply Voltage | AC380V/50Hz | ||||
| Power Consumption | 8.5KW | 9KW | 12KW | 18KW | 18K |
| Ambient Temperature | 5~35 ℃ | ||||
1. GB/T16422-2-1999 Laboratory light source exposure test methods for plastics — Part 2: Xenon arc lamp
2. GB12831-1991 Artificial climate (xenon lamp) ageing test method for vulcanised rubber
3. GB/T 8430-1998 Textiles - Colour fastness tests - Resistance to artificial light - Xenon arc
4. GB/T 1865-2009 Paints and varnishes - Artificial ageing and artificial radiation exposure - Filtered xenon arc radiation
5. GB/T 13448-2006 Coloured coated steel sheets and strips - Test methods
6. GB/T 2423.24-1995 Environmental Testing of Electrical and Electronic Products - Part 2: Test Methods - Test Sa: Simulation of Solar Radiation at Ground Level
7. ASTM D3499-2011 Test Method for Toughness of Plywood
8. ASTM G151-2010 Exposure Protocol for Non-Metallic Materials in Accelerated Test Apparatus Using Laboratory Light Sources
9. ASTM G155-2005a Operating Procedures for Xenon Arc Lamp Equipment for Exposure of Non-Metallic Materials
10. AATCC TM169 Weather Resistance of Textiles - Xenon Arc Exposure Test
11. ISO 4892-2-2009 Plastics - Laboratory light exposure methods - Part 2: Xenon arc lamp and other international standards
1. Fan overheating protection
2. Whole unit phase loss/reverse phase protection
3. Refrigeration system overload protection
4. Refrigeration system overpressure protection
5. Overtemperature protection
6. Water pump overheating and overcurrent protection
7. Earth leakage protection
8. Low water level alert
9. Fault alarm & automatic shutdown
